• Country
• Germany

• Manufacturer / Brand
• Philips Radios - Deutschland

• Year
• 1959/1960

• Category
• Sound/Video Recorder and/or Player

• Radiomuseum.org ID
• 129025

• • Brand: Deutsche Philips-Ges.

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 5

• Valves / Tubes
• ECC83 EF86 ECL82 EZ80 EM84

• Number of Transistors

• Semiconductors
• OA85

• Main principle
• Audio-Amplification

• Wave bands
• - without

• Details
• Tape Recorder

• Power type and voltage
• Alternating Current supply (AC) / 110; 127; 220; 240 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical / Ø 9.6 cm = 3.8 inch

• Power out
• 2.5 W (unknown quality)

• Material
• Leather / canvas / plastic - over other material

• from Radiomuseum.org
• Model: RK10 EL3515D /22a [helles Lautsprechergitter] - Philips Radios - Deutschland

• Shape
• Tablemodel, low profile (big size).

• Dimensions (WHD)
• 350 x 310 x 150 mm / 13.8 x 12.2 x 5.9 inch

• Notes
• Doppelspuraufzeichnung, Bandgeschwindigkeit 9,5cm/sec, Frequenzumfang 50-14000 Hz. Bis zu 18 cm Spulen. Anschluss für Fussschalter.

• Net weight (2.2 lb = 1 kg)
• 8 kg / 17 lb 9.9 oz (17.621 lb)

• Price in first year of sale
• 359.00 DM

• Source of data
• Funkschau

• Author
• Model page created by Wilfried Winter. See "Data change" for further contributors.
