• Country
• Netherlands

• Manufacturer / Brand
• Philips; Eindhoven (tubes international!); Miniwatt

• Year
• 1973–1976 ?

• Category
• Service- or Lab Equipment

• Radiomuseum.org ID
• 245336

Click on the schematic thumbnail to request the schematic as a free document.

• Wave bands
• VHF incl. FM and/or UHF (see notes for details)

• Power type and voltage
• Alternating Current supply (AC) / 220 Volt

• Loudspeaker
• - - No sound reproduction output.

• Material
• Plastics (no bakelite or catalin)

• from Radiomuseum.org
• Model: Generador patrón de tramas - Cross Hatch Pattern Generator SPG-221 - Philips; Eindhoven tubes

• Dimensions (WHD)
• 162 x 49 x 107 mm / 6.4 x 1.9 x 4.2 inch

• Notes

• VHF Canal 2 ( 57 ± 2 MHz )
  Modulación: PAL - SECAM - NTSC
  (cambiando conexiones soldadas en placas del circuito impreso)
  (changing soldered connections on printed circuit boards)

  See also the similar Philips model SPG 222 UHF



• Net weight (2.2 lb = 1 kg)
• 0.4 kg / 0 lb 14.1 oz (0.881 lb)

• Mentioned in
• ROU: Radio Taller Nº 8, pág. 29 Agosto 1976

• Literature/Schematics (1)
• Funk-Technik (FT) (21/1973, S. 820, 4/1974, S. 125, 128 / Bericht, Schema)

• Author
• Model page created by Carlos A. Pieroni-García. See "Data change" for further contributors.
