SQ2 LBB1250 /01
Philips; Eindhoven (tubes international!); Miniwatt
- Country
- Netherlands
- Manufacturer / Brand
- Philips; Eindhoven (tubes international!); Miniwatt
- Year
- 1967 ??
- Category
- Audio Amplifier or -mixer
- Radiomuseum.org ID
- 343393
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Transistors
- 15
- Semiconductors
- BC149 BC149 BC149 BC149 BC149 BC149 BC149 BC149 BC159 BC159 BFY56 BFY56 BDY20 BDY20 BAX13 BY126 BZX87
- Main principle
- Audio-Amplification
- Wave bands
- - without
- Power type and voltage
- Line / Storage batteries (perhaps also batteries) / 110; 127; 220; 245 / 24 Volt
- Loudspeaker
- - This model requires external speaker(s).
- Power out
- 25 W (undistorted)
- Material
- Metal case
- from Radiomuseum.org
- Model: SQ2 LBB1250 /01 - Philips; Eindhoven tubes
- Shape
- Book-shelf unit.
- Dimensions (WHD)
- 330 x 123 x 290 mm / 13 x 4.8 x 11.4 inch
- Notes
-
See also LBB1250 /00
- Net weight (2.2 lb = 1 kg)
- 6.350 kg / 13 lb 15.8 oz (13.987 lb)
- Literature/Schematics (1)
- -- Original-techn. papers.
- Author
- Model page created by Miguel Bravo-Cos. See "Data change" for further contributors.
