• Country
• Germany

• Manufacturer / Brand
• Philips Radios - Deutschland

• Year
• 1973–1975

• Category
• Sound/Video Recorder and/or Player

• Radiomuseum.org ID
• 29186

• • Brand: Deutsche Philips-Ges.

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 15

• Semiconductors

• Main principle
• Audio-Amplification

• Wave bands
• - without

• Details
• Cassette-Recorder or -Player

• Power type and voltage
• Alternating Current supply (AC) / 110; 127; 220; 240 Volt

• Loudspeaker
• - This model requires external speaker(s).

• Material
• Wooden case

• from Radiomuseum.org
• Model: N2400LS - Philips Radios - Deutschland

• Shape
• Tablemodel with Push Buttons.

• Dimensions (WHD)
• 350 x 70 x 220 mm / 13.8 x 2.8 x 8.7 inch

• Notes
• Stereo-NF-Verstärker mit 2 Endstufen je 5 W; zwei Lautsprecherboxen 22RH421 gehören zum Lieferumfang. Übertragungsbereich: 60-10000 Hz.

• Net weight (2.2 lb = 1 kg)
• 3 kg / 6 lb 9.7 oz (6.608 lb)

• External source of data
• Erb

• Source of data
• Katalog RFP 1973
