Stereo-Cassetten-Recorder N2400 /00 /15 /16 /19 /22 /60

• Country
• Netherlands

• Manufacturer / Brand
• Philips; Eindhoven (tubes international!); Miniwatt

• Year
• 1971–1976

• Category
• Sound/Video Recorder and/or Player

• Radiomuseum.org ID
• 28500

• Picture
• Schematics

Previous Next

Previous Next

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 15

• Semiconductors

• Main principle
• Audio-Amplification

• Wave bands
• - without

• Details
• Cassette-Recorder or -Player

• Power type and voltage
• Alternating Current supply (AC) / 110; 127; 220; 240 Volt

• Loudspeaker
• - For headphones or amp.

• Material
• Wooden case

• from Radiomuseum.org
• Model: Stereo-Cassetten-Recorder N2400 [/00 /15 /16 /19 /22 /60] - Philips; Eindhoven tubes

• Shape
• Tablemodel with Push Buttons.

• Dimensions (WHD)
• 350 x 70 x 220 mm / 13.8 x 2.8 x 8.7 inch

• Notes

• Philips Cassetten-Recorder N2400 in 6 Ausführungen.
  Ausgangsleistung: 2× 5 W (Sinus); Frequenzumfang: 60···10000 Hz.
  Siehe auch N2400LS als Komplettanlage mit zwei Lautsprecherboxen.

  Philips cassette recorder N2400 in 6 versions.
  Output power: 2 × 5 W (sine wave); Frequency range: 60 ··· 10000 Hz.
  See also N2400LS as a complete system with two speakers.

  Inputs for Radio, Microphone and Phono.

• Net weight (2.2 lb = 1 kg)
• 3 kg / 6 lb 9.7 oz (6.608 lb)

• Price in first year of sale
• 349.00 DM

• External source of data
• Erb

• Source of data
• Handbuch VDRG 1971/1972

• Mentioned in
• Handbuch VDRG 1975/1976

• Literature/Schematics (1)
• -- Original-techn. papers.
