• Country
• Netherlands

• Manufacturer / Brand
• Philips; Eindhoven (tubes international!); Miniwatt

• Year
• 1976 ??

• Category
• Sound/Video Recorder and/or Player

• Radiomuseum.org ID
• 287038

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors

• Semiconductors
• BY206 BY206 BY126 TCA830 TCA830 TDA1059

• Main principle
• Audio-Amplification

• Wave bands
• - without

• Details
• Rec.Player+Audio.Amp+LS

• Power type and voltage
• 50-60 Hz, 110; 127; 220; 240 / D: 6 x 1,5 Volt

• Loudspeaker
• 2 Loudspeakers

• Material
• Plastics (no bakelite or catalin)

• from Radiomuseum.org
• Model: Stereo - Electrophon SG2623 /22 - Philips; Eindhoven tubes

• Shape
• Portable set > 8 inch (also usable without mains)

• Dimensions (WHD)
• 400 x 140 x 255 mm / 15.7 x 5.5 x 10 inch

• Notes

• Mögliche steckbare Tonköpfe mit Abtastnadeln (Mikrorille):

  • GP 214 (Saphir)
  • GP 215 (Diamant)

  Das Schema führt die Bezeichnung TSF21 für den Motorregler-IC, möglicherweise eine Philips-interne Type. Tatsächlich ist das IC TDA1059 verbaut worden.

  Probably made in France.

• Mentioned in
• - - Manufacturers Literature

• Literature/Schematics (1)
• -- Schematic

• Author
• Model page created by Ottmar Lauth. See "Data change" for further contributors.
