Transistor Testapparaat PP2010

• Country
• Netherlands

• Manufacturer / Brand
• Philips; Eindhoven (tubes international!); Miniwatt

• Year
• 1959 ??

• Category
• Service- or Lab Equipment

• Radiomuseum.org ID
• 173597

• Picture
• Schematics

Previous Next

Previous Next

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 1

• Valves / Tubes
• 90C1

• Number of Transistors
• Semiconductors present.

• Semiconductors
• GJ5M OA31 OA31 OA31 OA31

• Wave bands
• - without

• Power type and voltage
• Alternating Current supply (AC) / 110; 125; 205; 220; 235; 250 Volt

• Loudspeaker
• - - No sound reproduction output.

• Material
• Metal case

• from Radiomuseum.org
• Model: Transistor Testapparaat PP2010 - Philips; Eindhoven tubes

• Shape
• Tablemodel, slant panel.

• Dimensions (WHD)
• 433 x 190 x 314 mm / 17 x 7.5 x 12.4 inch

• Notes
• Manufactured for Philips by M.E.L., London.
  Supplied collector voltage 0-3V variable, 2-30V in 8 steps. Zener range 2,5mW for 0-30V, 25 and 250mW for 0-100V.
  Measurements: Zener voltage of the collector, collector current and and current gain for NPN and PNP transistors.

• Net weight (2.2 lb = 1 kg)
• 9 kg / 19 lb 13.2 oz (19.824 lb)

• Literature/Schematics (1)
• -- Original-techn. papers.

• Author
• Model page created by Georg Richter. See "Data change" for further contributors.
