unbekannt (6 Röhren)
Unknown - CUSTOM BUILT: Switzerland (CH)
- Country
- Switzerland
- Manufacturer / Brand
- Unknown - CUSTOM BUILT: Switzerland (CH)
- Year
- 1934 ?
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 247414
- Number of Tubes
- 6
- Main principle
- Superhet with RF-stage
- Tuned circuits
- 7 AM circuit(s)
- Wave bands
- Broadcast (MW) and Long Wave.
- Power type and voltage
- Alternating Current supply (AC) / 110 Volt
- Loudspeaker
- Electro Magnetic Dynamic LS (moving-coil with field excitation coil) / Ø 16 cm = 6.3 inch
- Material
- Wooden case
- from Radiomuseum.org
- Model: unbekannt - Unknown - CUSTOM BUILT:
- Shape
- Tablemodel, Tombstone = decorative upright, not cathedral but can have rounded edges.
- Dimensions (WHD)
- 340 x 360 x 210 mm / 13.4 x 14.2 x 8.3 inch
- Notes
-
Gehäuse wurde in der Schweiz gefertigt. Das Chassis stammt sehr wahrscheinlich aus den USA. Magnavox lautsprecher. Philips (und Telefunken?) Lizenz wahrscheinlich zum Verkauf in der Schweiz.
- Net weight (2.2 lb = 1 kg)
- 6.3 kg / 13 lb 14 oz (13.877 lb)
- Author
- Model page created by Matteo Agustoni. See "Data change" for further contributors.
