Worms 110 L Vitrine - D26K175 D 26 K 175 Ch=K8D
Philips Radios - Deutschland
- Country
- Germany
- Manufacturer / Brand
- Philips Radios - Deutschland
- Year
- 1971/1972
- Category
- Television Receiver (TV) or Monitor
- Radiomuseum.org ID
- 104869
-
- Brand: Deutsche Philips-Ges.
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 15
- Number of Transistors
- 79
- Semiconductors
- Main principle
- Superheterodyne (common)
- Wave bands
- Wave Bands given in the notes.
- Details
- Remote Control (with wire or wireless)
- Power type and voltage
- Alternating Current supply (AC) / 220 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
- Material
- Wooden case
- from Radiomuseum.org
- Model: Worms 110 L Vitrine - D26K175 D 26 K 175 Ch=K8D - Philips Radios - Deutschland
- Shape
- Console, Lowboy (legs < 50 %).
- Dimensions (WHD)
- 910 x 880 x 550 mm / 35.8 x 34.6 x 21.7 inch
- Notes
- 89 Dioden, 2 ICs. Röhren teilweise mehrfach vorhanden. Tuner mit Kapazitätsdioden für VHF und UHF.
Letztes Philips CTV-Röhren-Chassis mit 110° Dickhalsröhre.
- Net weight (2.2 lb = 1 kg)
- 65 kg / 143 lb 2.7 oz (143.172 lb)
- Source of data
- Handbuch VDRG 1971/1972
- Mentioned in
- -- Original-techn. papers.
- Author
- Model page created by Franz Born †. See "Data change" for further contributors.
