- Country
- Spain
- Manufacturer / Brand
- Philips Ibérica, COPRESA, Compañía de Productos Electrónicos, Miniwatt tubes, SELEZ; Madrid, Barcelona
- Year
- 1958
- Category
- Television Receiver (TV) or Monitor
- Radiomuseum.org ID
- 235050
Foto del manual técnico
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 21
- Valves / Tubes
- PCC84 PCF80 PCF80 PCF80 PL82 EF80 EF80 EF80 EF80 PL83 ECH81 PCF80 PCF80 PL81 PY81 DY86 ECC82 PL82 PY82 PY82 PY82 MW53-20
- Number of Transistors
- Main principle
- Superheterodyne (common); ZF/IF 38900/33400 kHz
- Wave bands
- VHF incl. FM and/or UHF (see notes for details)
- Power type and voltage
- Alternating Current supply (AC) / 90; 110; 125; 145; 160; 220 Volt
- Loudspeaker
- 2 Loudspeakers
- Material
- Wooden case
- from Radiomuseum.org
- Model: 21-CE-140-A-02 - Philips Ibérica, COPRESA,
- Shape
- Console, Lowboy (legs < 50 %).
- Dimensions (WHD)
- 645 x 990 x 600 mm / 25.4 x 39 x 23.6 inch
- Notes
-
TRC: 21" (53 cm.)
Selector rotativo de 12 canales pero sólo lleva las bobinas del canal 3 VHF (54-61 MHz.)
- Literature/Schematics (2)
- -- Original-techn. papers.
- Author
- Model page created by Miguel Bravo-Cos. See "Data change" for further contributors.
