- Country
- Spain
- Manufacturer / Brand
- Philips Ibérica, COPRESA, Compañía de Productos Electrónicos, Miniwatt tubes, SELEZ; Madrid, Barcelona
- Year
- 1967
- Category
- Sound/Video Recorder and/or Player
- Radiomuseum.org ID
- 199326
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Transistors
- 11
- Semiconductors
- Main principle
- Audio-Amplification
- Wave bands
- - without
- Details
- Tape Recorder
- Power type and voltage
- Alternating Current supply (AC) / 125; 220 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 6 inch = 15.2 cm
- Power out
- 2 W (unknown quality)
- Material
- Various materials
- from Radiomuseum.org
- Model: N-4306/18 - Philips Ibérica, COPRESA,
- Shape
- Tablemodel, low profile (big size).
- Dimensions (WHD)
- 402 x 135 x 295 mm / 15.8 x 5.3 x 11.6 inch
- Notes
- 4 pistas, 2 velocidades: 4,75 & 9,5 cm/s. Stereo.
- Net weight (2.2 lb = 1 kg)
- 7 kg / 15 lb 6.7 oz (15.419 lb)
- Author
- Model page created by Alberto Sanna-Alonso. See "Data change" for further contributors.
