• Country
• New Zealand-Aotearoa

• Manufacturer / Brand
• Philips Electrical Industries of New Zealand Ltd.; Wellington

• Year
• 1952

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 341642

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 5

• Valves / Tubes
• ECH42 EAF42 EBC41 EL41 EZ40

• Main principle
• Superheterodyne (common); ZF/IF 455 kHz; 2 AF stage(s)

• Tuned circuits
• 6 AM circuit(s)

• Wave bands
• Broadcast plus 2 Short Wave bands.

• Power type and voltage
• Alternating Current supply (AC) / 230 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)

• Material
• Wooden case

• from Radiomuseum.org
• Model: BZ426A - Philips Electrical Industries

• Shape
• Tablemodel, low profile (big size).

• Notes

• Philips BZ426A

  5-Valve superhet 3 band receiver.

• Price in first year of sale
• 32.50 NZ £

• Mentioned in
• -- Original prospect or advert (Press 6 May 1952 Page 10)

• Author
• Model page created by Brian Stevens. See "Data change" for further contributors.
