• Country
• New Zealand-Aotearoa

• Manufacturer / Brand
• Philips Electrical Industries of New Zealand Ltd.; Wellington

• Year
• 1940

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 335069

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 4

• Valves / Tubes
• ECH3 EBF2 EL3 AZ1

• Main principle
• Superheterodyne (common); ZF/IF 472.5 kHz; 2 AF stage(s)

• Tuned circuits
• 6 AM circuit(s)

• Wave bands
• Broadcast and Short Wave (SW).

• Power type and voltage
• Alternating Current supply (AC) / 230 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)

• Material
• Wooden case

• from Radiomuseum.org
• Model: Radioplayer 042 - Philips Electrical Industries

• Shape
• Tablemodel, with any shape - general.

• Dimensions (WHD)
• 18.25 x 11.5 x 8 inch / 464 x 292 x 203 mm

• Notes

• 4-valve, AC-powered Dual band superhet

• Author
• Model page created by Brian Stevens. See "Data change" for further contributors.
