• Country
• Italy

• Manufacturer / Brand
• Phonola SA, FIMI; Saronno (VA)

• Year
• 1950–1953

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 125358

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 13

• Valves / Tubes
• EF42 ECC40 EF42 EF42 EM4 EF42 EB41 ECH42 EBF32 ECC40 EL41 EL41 AZ2

• Main principle
• Superheterodyne (common); ZF/IF 470/10500 kHz

• Tuned circuits
• 6 AM circuit(s)     9 FM circuit(s)

• Wave bands
• Wave Bands given in the notes.

• Details
• Record Player + Tape Recorder

• Power type and voltage
• Alternating Current supply (AC) / 100-270 Volt

• Loudspeaker
• 2 Loudspeakers

• Material
• Wooden case

• from Radiomuseum.org
• Model: 1102 Fono - Phonola SA, FIMI; Saronno VA

• Shape
• Console with any shape - in general

• Dimensions (WHD)
• 1130 x 600 x 440 mm / 44.5 x 23.6 x 17.3 inch

• Notes

• Radiofonoregistratore, altoparlanti magnetodinamici, mobile in legno con discoteca.
  Gamme d'onda: 2 x OM, 6 x OC, FM.

  Separate RF/IF units for AM and FM reception.

• Price in first year of sale
• 400,000.00 ITL

• Mentioned in
• Catalogo Antique Radio, Vol. II

• Author
• Model page created by Giuseppe Antonio Tusini. See "Data change" for further contributors.
