603 Ch= 600
Phonola SA, FIMI; Saronno (VA)
- Country
- Italy
- Manufacturer / Brand
- Phonola SA, FIMI; Saronno (VA)
- Year
- 1933–1935
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 124472
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 6
- Main principle
- Superheterodyne (common); ZF/IF 175 kHz
- Tuned circuits
- 9 AM circuit(s)
- Wave bands
- Broadcast, Long Wave and Short Wave.
- Details
- Record Player (not changer)
- Power type and voltage
- Alternating Current supply (AC) / 125-220 Volt
- Loudspeaker
- Electro Magnetic Dynamic LS (moving-coil with field excitation coil)
- Material
- Wooden case
- from Radiomuseum.org
- Model: 603 Ch= 600 - Phonola SA, FIMI; Saronno VA
- Shape
- Console, Lowboy (legs < 50 %).
- Notes
- Radiofonografo 78 rpm. Serie Transoceanica.
Con il medesimo chassis "600" sono stati costruiti anche i modelli 600,601,602,604,605,612 che differivano solo per il mobile esterno e l'eventuale giradischi a 78 rpm.
- Price in first year of sale
- 2,800.00 ITL
- Source of data
- Guida Pratica Antique Radio II (2000)
- Mentioned in
- Catalogo Antique Radio, Vol. II (.)
- Author
- Model page created by Giuseppe Antonio Tusini. See "Data change" for further contributors.
