SX1050 /38R
Phonola SA, FIMI; Saronno (VA)
- Country
- Italy
- Manufacturer / Brand
- Phonola SA, FIMI; Saronno (VA)
- Year
- 1975 ??
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 192403
- Number of Transistors
- 11
- Semiconductors
- Main principle
- Superheterodyne (common)
- Tuned circuits
- 5 AM circuit(s) 7 FM circuit(s)
- Wave bands
- Broadcast (BC) and FM or UHF.
- Power type and voltage
- Dry Batteries / 4 x 1,5 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 5.5 cm = 2.2 inch
- Material
- Plastics (no bakelite or catalin)
- from Radiomuseum.org
- Model: SX1050 /38R - Phonola SA, FIMI; Saronno VA
- Shape
- Very small Portable or Pocket-Set (Handheld) < 8 inch.
- Dimensions (WHD)
- 140 x 76 x 41 mm / 5.5 x 3 x 1.6 inch
- Notes
-
Gamme d'onda:
FM: 88-104 MHz
OM: 550-1600 kHz
Presa auricolare sul retro
Identica ai modelli Hornyphon Benjamin SX1050 e anche alla Erres Radioportable SX1050
- Author
- Model page created by Manuel Zenato. See "Data change" for further contributors.
