• Year
  • 1969 ??
  • Category
  • Television Receiver (TV) or Monitor
  • Radiomuseum.org ID
  • 165621

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Tubes
  • 15
  • Number of Transistors
  • 2
  • Semiconductors
  • Main principle
  • Superheterodyne (common); ZF/IF 38900/5500 kHz
  • Wave bands
  • Wave Bands given in the notes.
  • Power type and voltage
  • Alternating Current supply (AC) / 220 Volt
  • Loudspeaker
  • 2 Loudspeakers
  • Material
  • Wooden case
  • from Radiomuseum.org
  • Model: TV-2085 - Phonola SA, FIMI; Saronno VA
  • Shape
  • Tablemodel, low profile (big size).
  • Notes
  • Cinescopio Panoramico 20 pollici defflessione 110° autoprotetto tipo A51-10W opp. A50-120W
    Prese antenna VHF e UHF
    Gamma VHF Banda I - III
    Gamma UHF Banda IV - V
