• Country
• Italy

• Manufacturer / Brand
• Phonola SA, FIMI; Saronno (VA)

• Year
• 1957 ??

• Category
• Television Receiver (TV) or Monitor

• Radiomuseum.org ID
• 171044

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 22

• Valves / Tubes
• PCC84 PCF80 EF80 EF80 EF80 EF80 PL83 EF80 EF80 EF80 EABC80 EL84 PCF80 PCL82 EB91 ECC82 PL36 PY81 5Y3 5X4G EY86 24CP4

• Main principle
• Superheterodyne (common)

• Wave bands
• Wave Bands given in the notes.

• Power type and voltage
• Alternating Current supply (AC) / 100-270 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)

• Material
• Wooden case

• from Radiomuseum.org
• Model: TV-2402 - Phonola SA, FIMI; Saronno VA

• Shape
• Console: Chairside Radio.

• Notes
• Cinescopio 24" 90° tipo sferico- magnetico.
  VHF (S4).
  FI 4 stadi 40 MHz sistema intercarrier.
  Comandi frontali, interruttore con chiave.
  Mobile consolle.

• Literature/Schematics (1)
• -- Schematic (Schemario dei Televisori Phonola 1952 al 1964)

• Author
• Model page created by Eduard Abfalterer. See "Data change" for further contributors.

• Other Models

• Here you find 716 models, 460 with images and 545 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
  All listed radios etc. from Phonola SA, FIMI; Saronno (VA)
