• Country
• Germany

• Manufacturer / Brand
• Phywe, Physikalische Werkstätten A.G.; Göttingen

• Year
• 1954 ??

• Category
• Teaching aids-material

• Radiomuseum.org ID
• 164436

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 1

• Valves / Tubes
• ECL80

• Power type and voltage
• Powered by external power supply or a main unit.

• Material
• Metal case

• from Radiomuseum.org
• Model: Röhrenplatte für ECL80 CL - Phywe, Physikalische

• Dimensions (WHD)
• 320 x 280 x 80 mm / 12.6 x 11 x 3.1 inch

• Notes
• Modul aus Funk-Lehrgerät.Betriebsspannungen aus dem Netzteil im Aufbaurahmen.Einsetzbar als,Demodulations-und Endstufe.

• Net weight (2.2 lb = 1 kg)
• 1.850 kg / 4 lb 1.2 oz (4.075 lb)

• Author
• Model page created by Rudolf Osterkamp. See "Data change" for further contributors.
