BS647
Pilot Radio Ltd.; London
- Country
- Great Britain (UK)
- Manufacturer / Brand
- Pilot Radio Ltd.; London
- Year
- 1948 ?
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 320190
- Number of Tubes
- 6
- Main principle
- Superheterodyne (common); ZF/IF 451 kHz
- Tuned circuits
- 1 AM circuit(s)
- Wave bands
- Broadcast plus more than 2 Short Wave bands.
- Power type and voltage
- Alternating Current supply (AC) / 110-130; 220-225; 225-250 Volt Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 7.9 inch = 20.1 cm
- Power out
- 4.5 W (undistorted)
- Material
- Wooden case
- from Radiomuseum.org
- Model: BS647 - Pilot Radio Ltd.; London
- Shape
- Tablemodel, slant panel.
- Dimensions (WHD)
- 11 x 12 x 20 inch / 279 x 305 x 508 mm
- Net weight (2.2 lb = 1 kg)
- 9.6 kg / 21 lb 2.3 oz (21.145 lb)
- Author
- Model page created by Uday Kalburgi. See "Data change" for further contributors.
