Spider K-527
Pilot Electric Mfg. Co. (Radio Corp.); Brooklyn (NY)
- Country
- United States of America (USA)
- Manufacturer / Brand
- Pilot Electric Mfg. Co. (Radio Corp.); Brooklyn (NY)
- Year
- 1932
- Category
- Pre-stage (adaptor for SW/FM/VHF/UHF incl. built-in), Frequency converter
- Radiomuseum.org ID
- 292104
-
- alternative name: Pilot Radio & Television || Pilot Radio and Tube || Pilot Radio Corporation
Pilot Spring Catalog 1932, page 16
- Number of Tubes
- 3
- Main principle
- RF Converter/Adapter (not voltage converter)
- Wave bands
- Short Wave (SW only)
- Power type and voltage
- Alternating Current supply (AC) / 110-240 Volt
- Loudspeaker
- - - No sound reproduction output.
- Material
- Metal case
- from Radiomuseum.org
- Model: Spider K-527 - Pilot Electric Mfg. Co. Radio
- Shape
- Chassis only or for «building in»
- Notes
-
AC powered shortwave converter using plug in coils to cover 20 to 200 Metres band.
Supplied as a kit with various AC supply voltages available on order.
K-527
110-115 Volts, 50-60Hz
K-527F
125 Volts, 50-60Hz
K-527A
220 Volts, 50-60Hz
K-527B
240 Volts, 50-60Hz
K-527J
110-115 Volts, 25Hz
K-527FJ
125 Volts, 25Hz
- Mentioned in
- Pilot Spring Catalog 1932, page 16
- Author
- Model page created by Gary Cowans. See "Data change" for further contributors.
