• Country
• Israel

• Manufacturer / Brand
• Pilot; (where?)

• Year
• 1960 ??

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 300585

• Number of Tubes
• 4

• Valves / Tubes
• ECH81 EBF89 ECL82 EZ80

• Main principle
• Superheterodyne (common); 2 AF stage(s)

• Wave bands
• Broadcast only (MW).

• Power type and voltage
• Alternating Current supply (AC) / 220 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)

• Material
• Wooden case

• from Radiomuseum.org
• Model: Star - Pilot; where?

• Shape
• Tablemodel without push buttons, Mantel/Midget/Compact up to 14

• Dimensions (WHD)
• 345 x 185 x 170 mm / 13.6 x 7.3 x 6.7 inch

• Notes

• See also similar model Bambi.

• Net weight (2.2 lb = 1 kg)
• 3.8 kg / 8 lb 5.9 oz (8.37 lb)

• Author
• Model page created by Karol Gillon. See "Data change" for further contributors.
