8 Track Stereo Recording Deck H-R100

Pioneer Corporation; Tokyo

Data

Forum

Pictures

Collections

Country
Japan

Manufacturer / Brand
Pioneer Corporation; Tokyo

Year
1975 ??

Category
Sound/Video Recorder and/or Player

Radiomuseum.org ID
343819

Schematics

8 Track Stereo Recording Deck H-R100; Pioneer Corporation; (ID = 2846762) R-Player — Pioneer Corporation; 8 Track Stereo Recording Deck H-R100 (2)
eBay item number:225353204441

8 Track Stereo Recording Deck H-R100; Pioneer Corporation; (ID = 2846763) R-Player — Pioneer Corporation; 8 Track Stereo Recording Deck H-R100 (2)
eBay item number:225353204441

8 Track Stereo Recording Deck H-R100; Pioneer Corporation; (ID = 2846764) R-Player — Pioneer Corporation; 8 Track Stereo Recording Deck H-R100 (2)
eBay item number:225353204441

8 Track Stereo Recording Deck H-R100; Pioneer Corporation; (ID = 2847080) R-Player — Pioneer Corporation; 8 Track Stereo Recording Deck H-R100 (2)
eBay item number:225318447228

8 Track Stereo Recording Deck H-R100; Pioneer Corporation; (ID = 2847081) R-Player — Pioneer Corporation; 8 Track Stereo Recording Deck H-R100 (2)
eBay item number:225318447228

8 Track Stereo Recording Deck H-R100; Pioneer Corporation; (ID = 2847082) R-Player — Pioneer Corporation; 8 Track Stereo Recording Deck H-R100 (2)
eBay item number:225318447228

8 Track Stereo Recording Deck H-R100; Pioneer Corporation; (ID = 2847083) R-Player — Pioneer Corporation; 8 Track Stereo Recording Deck H-R100 (2)
eBay item number:225318447228

8 Track Stereo Recording Deck H-R100; Pioneer Corporation; (ID = 2847084) R-Player — Pioneer Corporation; 8 Track Stereo Recording Deck H-R100 (2)
eBay item number:225318447228

8 Track Stereo Recording Deck H-R100; Pioneer Corporation; (ID = 2847085) R-Player — Pioneer Corporation; 8 Track Stereo Recording Deck H-R100 (2)
eBay item number:225318447228

8 Track Stereo Recording Deck H-R100; Pioneer Corporation; (ID = 2847086) R-Player — Pioneer Corporation; 8 Track Stereo Recording Deck H-R100 (2)
eBay item number:225318447228

8 Track Stereo Recording Deck H-R100; Pioneer Corporation; (ID = 2847087) R-Player — Pioneer Corporation; 8 Track Stereo Recording Deck H-R100 (2)
Pioneer Service Manual

Technical Specifications

Number of Transistors
31

Semiconductors

Main principle
Audio-Amplification

Wave bands
- without

Details
Special Tape or Cassette-Format

Power type and voltage
Alternating Current supply (AC) / 50-60 Hz, 120; 220; 240 Volt

Loudspeaker
- For headphones or amp.

Material
Metal case

from Radiomuseum.org
Model: 8 Track Stereo Recording Deck H-R100 - Pioneer Corporation; Tokyo

Shape
Book-shelf unit.

Dimensions (WHD)
295 x 116 x 275 mm / 11.6 x 4.6 x 10.8 inch

Notes
8 Track Home Stereo Recording Deck Model Pioneer H-R100

Dolby NR
Frequency Response: 30Hz to 15kHz
Wow and Flutter: 0.15%
3-digit Tape Counter

Finish:
Walnut grained vinyl cabinet - Wooden Side Panels

Power Consumption 25 Watts

Net weight (2.2 lb = 1 kg)
5.6 kg / 12 lb 5.4 oz (12.335 lb)
