• Country
• Japan

• Manufacturer / Brand
• Pioneer Corporation; Tokyo

• Year
• 1975

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 198361

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• Semiconductors present.

• Semiconductors

• Main principle
• Superheterodyne (common)

• Wave bands
• Broadcast (BC) and FM or UHF.

• Details
• Record Player (not changer)

• Power type and voltage
• Alternating Current supply (AC) / 220 Volt

• Loudspeaker
• - This model requires external speaker(s).

• Material
• Wooden case

• from Radiomuseum.org
• Model: C-4600 X - Pioneer Corporation; Tokyo

• Shape
• Tablemodel, low profile (big size).

• Dimensions (WHD)
• 517 x 172 x 398 mm / 20.4 x 6.8 x 15.7 inch

• Notes
• Pioneer C-4600 X;
  FM Stereo tuner.

• Mentioned in
• (A) Radio Elektronik Schau; Heft 11, 1975 Kurzvorstellung

• Author
• Model page created by a member from A. See "Data change" for further contributors.
