FM/AM Digital Synthesizer Tuner TX-221Z
Pioneer Corporation; Tokyo
- Country
- Japan
- Manufacturer / Brand
- Pioneer Corporation; Tokyo
- Year
- 1985 ?
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 330706
- Number of Transistors
- Semiconductors present.
- Semiconductors
- Main principle
- PLL, Phase-locked loop
- Wave bands
- Broadcast (BC) and FM or UHF.
- Power type and voltage
- Other, details in remarks or not known.
- Loudspeaker
- - For headphones or amp.
- Material
- Metal case
- from Radiomuseum.org
- Model: FM/AM Digital Synthesizer Tuner TX-221Z - Pioneer Corporation; Tokyo
- Shape
- Book-shelf unit.
- Dimensions (WHD)
- 420 x 60 x 200 mm / 16.5 x 2.4 x 7.9 inch
- Notes
-
Die Stromversorgung und der Audioanschluss erfolgt über ein Spezialkabel zum Verstärker Pioneer DC-221Z oder DC-111Z. Der Tuner kann nur mit diesen Verstärkern betrieben werden.
- Net weight (2.2 lb = 1 kg)
- 1.7 kg / 3 lb 11.9 oz (3.744 lb)
- Author
- Model page created by Matthias Buhl. See "Data change" for further contributors.
