KE-4300

Pioneer Corporation; Tokyo

Data
Forum
Pictures
Collections

  • Year
  • 1982 ?
  • Category
  • Car Radio, perhaps also + sound player/recorder
  • Radiomuseum.org ID
  • 342335

 Technical Specifications

  • Number of Transistors
  • Semiconductors present.
  • Semiconductors
  • Main principle
  • Superheterodyne (common)
  • Wave bands
  • Broadcast, Long Wave and FM or UHF.
  • Details
  • Cassette-Recorder or -Player
  • Power type and voltage
  • Storage Battery for all (e.g. for car radios and amateur radios) / 12 Volt
  • Loudspeaker
  • - This model requires external speaker(s).
  • Power out
  • 13 W (max.)
  • Material
  • Metal case
  • from Radiomuseum.org
  • Model: KE-4300 - Pioneer Corporation; Tokyo
  • Shape
  • Chassis only or for «building in»
  • Dimensions (WHD)
  • 180 x 50 x 150 mm / 7.1 x 2 x 5.9 inch
  • Notes

  • Cassette Car Stereo with LW/MW/FM Electronic Tuner Model Pioneer KE4300

    FM 88 - 108 MHz
    AM 525 - 1605 kHz
    LW 150 - 280 kHz

    Tape Player with Auto-Reverse  50 -12000 Hz (+/-3dB)




  • Net weight (2.2 lb = 1 kg)
  • 1.8 kg / 3 lb 15.4 oz (3.965 lb)
  • Mentioned in
  • -- Original prospect or advert (Pioneer Car Stereo Dec.'82)
  • Author
  • Model page created by Franz Scharner. See "Data change" for further contributors.
