Stereo Receiver SX-3400
Pioneer Corporation; Tokyo
- Country
- Japan
- Manufacturer / Brand
- Pioneer Corporation; Tokyo
- Year
- 1980 ?
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 294864
- Number of Transistors
- 27
- Semiconductors
- Main principle
- Superheterodyne (common)
- Wave bands
- Broadcast (BC) and FM or UHF.
- Power type and voltage
- Alternating Current supply (AC) / 110; 120; 220; 240 Volt
- Loudspeaker
- - This model requires external speaker(s).
- Power out
- 30 W (undistorted)
- Material
- Metal case
- from Radiomuseum.org
- Model: Stereo Receiver SX-3400 - Pioneer Corporation; Tokyo
- Shape
- Tablemodel, low profile (big size).
- Dimensions (WHD)
- 444 x 128 x 292 mm / 17.5 x 5 x 11.5 inch
- Notes
-
Export model version. USA and Canada models 120 V only
Inputs: Phono 2,5 mV/50kΩ and Aux-Tape Play 150 mV/50kΩ
- Net weight (2.2 lb = 1 kg)
- 5.5 kg / 12 lb 1.8 oz (12.115 lb)
- Author
- Model page created by Stavros Stavrou. See "Data change" for further contributors.
