Stereo Receiver SX-727
Pioneer Corporation; Tokyo
- Country
- Japan
- Manufacturer / Brand
- Pioneer Corporation; Tokyo
- Year
- 1972
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 150846
Prospekt
- Number of Transistors
- 56
- Semiconductors
- Main principle
- Superheterodyne (common)
- Wave bands
- Broadcast (BC) and FM or UHF.
- Power type and voltage
- Alternating Current supply (AC) / 110; 120; 130; 220; 240 Volt
- Loudspeaker
- - This model requires external speaker(s).
- Power out
- 138 W (unknown quality)
- Material
- Metal case
- from Radiomuseum.org
- Model: Stereo Receiver SX-727 - Pioneer Corporation; Tokyo
- Shape
- Book-shelf unit.
- Dimensions (WHD)
- 485 x 150 x 390 mm / 19.1 x 5.9 x 15.4 inch
- Notes
- AM/FM-Stereo-Receiver mit 2 x 69 Watt Sinus an 4 Ohm.
56 Transistoren, 4 FET's, 37 Dioden und 4 IC's.
- Net weight (2.2 lb = 1 kg)
- 14 kg / 30 lb 13.4 oz (30.837 lb)
- Source of data
- -- Original prospect or advert
- Mentioned in
- Pioneer - mehr als nur HiFi 1972
- Author
- Model page created by Franz Scharner. See "Data change" for further contributors.
