• Country
• Germany

• Manufacturer / Brand
• Präcitronic Dresden, VEB; (Ostd.)

• Year
• 1971

• Category
• Service- or Lab Equipment

• Radiomuseum.org ID
• 154195

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 30

• Semiconductors
• SC239 SF136 SF137 GC101 GS112 SF121 SC206 SC207 SM104 SF127 SF126

• Wave bands
• - without

• Power type and voltage
• Alternating Current supply (AC) / 220 Volt

• Loudspeaker
• - - No sound reproduction output.

• Material
• Metal case

• from Radiomuseum.org
• Model: DC-Milli-Pico-Meter MV40 - Präcitronic Dresden, VEB; Ostd

• Shape
• Tablemodel, with any shape - general.

• Dimensions (WHD)
• 253 x 168 x 188 mm / 10 x 6.6 x 7.4 inch

• Notes

• Spannungsbereich:	10 µV - 300 V
  Strombereich:	1 pA - 300 µA
  Widerstandsmessung:	50 MΩ - 500 TΩ

  Isolationsprüfung mit 50 V Gleichspannung.

  Halbleitertypen nur einmal aufgeführt.

• Net weight (2.2 lb = 1 kg)
• 4.7 kg / 10 lb 5.6 oz (10.352 lb)

• Author
• Model page created by a member from D. See "Data change" for further contributors.
