Silicon Solid State Olimpia
Pravox; Treviglio (BG)
- Country
- Italy
- Manufacturer / Brand
- Pravox; Treviglio (BG)
- Year
- 1968 ??
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 262565
- Number of Transistors
- 6
- Main principle
- Superheterodyne (common)
- Tuned circuits
- 5 AM circuit(s)
- Wave bands
- Broadcast only (MW).
- Power type and voltage
- Line / Batteries (any type) / 220 / 6 x 1,5 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 5.5 cm = 2.2 inch
- Power out
- 1.5 W (undistorted)
- Material
- Plastics (no bakelite or catalin)
- from Radiomuseum.org
- Model: Silicon Solid State Olimpia - Pravox; Treviglio BG
- Shape
- Portable set > 8 inch (also usable without mains)
- Dimensions (WHD)
- 225 x 135 x 80 mm / 8.9 x 5.3 x 3.1 inch
- Notes
-
N.1diodo al germanio ed N.1 diodo al silicio.
N.1 ponte raddrizzatore.
Antenna interna.
- Net weight (2.2 lb = 1 kg)
- 0.450 kg / 0 lb 15.9 oz (0.991 lb)
- Author
- Model page created by Edoardo Sigismondo. See "Data change" for further contributors.
