Multi-socket Adapter G-140
Precision Apparatus Co. (Pacotronics); Brooklyn - Elmhurst - Glendale, NY / Chicago, IL
- Country
- United States of America (USA)
- Manufacturer / Brand
- Precision Apparatus Co. (Pacotronics); Brooklyn - Elmhurst - Glendale, NY / Chicago, IL
- Year
- 1961
- Category
- Service- or Lab Equipment
- Radiomuseum.org ID
- 152999
Click on the schematic thumbnail to request the schematic as a free document.
- Wave bands
- - without
- Power type and voltage
- Powered by external power supply or a main unit.
- Loudspeaker
- - - No sound reproduction output.
- Material
- Metal case
- from Radiomuseum.org
- Model: Multi-socket Adapter G-140 - Precision Apparatus Co.
- Shape
- Very small Portable or Pocket-Set (Handheld) < 8 inch.
- Dimensions (WHD)
- 2 x 5.25 x 1.25 inch / 51 x 133 x 32 mm
- Notes
- Multi-socket Adapter designed to enable you to check the Compactron, Nuvistor (both 5-pin and 7-pin types), Novar, and Ten-pin Miniature Tubes with any Tube Tester Models like 10-12, 10-15, 10-40, and 10-54 etc.
- Net weight (2.2 lb = 1 kg)
- 0 lb 6 oz (0.375 lb) / 0.170 kg
- Price in first year of sale
- 12.95 USD
- Source of data
- - - Manufacturers Literature
- Author
- Model page created by Ashis Mukerjea. See "Data change" for further contributors.
