Tube & Battery Tester 612 wooden case
Precision Apparatus Co. (Pacotronics); Brooklyn - Elmhurst - Glendale, NY / Chicago, IL
- Country
- United States of America (USA)
- Manufacturer / Brand
- Precision Apparatus Co. (Pacotronics); Brooklyn - Elmhurst - Glendale, NY / Chicago, IL
- Year
- 1948
- Category
- Service- or Lab Equipment
- Radiomuseum.org ID
- 133605
Test Probes provided with unit
TV Tube Adapter
aus ebay, #150674434406, Verkäufer jrcradio
manual
Gerät aus reparatur
Gerät aus reparatur
Gerät aus reparatur
Gerät aus reparatur
Gerät aus reparatur
Gerät aus reparatur
Gerät aus reparatur
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 1
- Valves / Tubes
- 5Y3GT
- Wave bands
- - without
- Power type and voltage
- Alternating Current supply (AC) / 117 Volt
- Loudspeaker
- - - No sound reproduction output.
- Material
- Wooden case
- from Radiomuseum.org
- Model: Tube & Battery Tester 612 [wooden case] - Precision Apparatus Co.
- Shape
- Tablemodel, low profile (big size).
- Dimensions (WHD)
- 13 x 7 x 14 inch / 330 x 178 x 356 mm
- Notes
- Line 90-130V, Neon Short Indicator, Condenser Test, Noise Test, Battery Test Voltage 0,75 - 300V, 10 Section 4Position Master Lever Switch.
- Net weight (2.2 lb = 1 kg)
- 13 lb 7 oz (13.438 lb) / 6.101 kg
- Price in first year of sale
- 72.00 USD
- Literature/Schematics (1)
- - - Manufacturers Literature
- Author
- Model page created by Willi Ribbe. See "Data change" for further contributors.
