• Country
• United States of America (USA)

• Manufacturer / Brand
• Premier Electric Co.; Chicago (IL)

• Year
• 1926

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 52257

• Number of Tubes
• 5

• Valves / Tubes
• UX201A UX201A UX201A UX201A UX201A

• Main principle
• TRF (Tuned-Radio-Frequency but use of regeneration unknown); 2 AF stage(s)

• Tuned circuits
• 3 AM circuit(s)

• Wave bands
• Broadcast only (MW).

• Power type and voltage
• Storage and/or dry batteries

• Loudspeaker
• - This model requires external speaker(s).

• Material
• Various materials

• from Radiomuseum.org
• Model: Ensemble - Premier Electric Co.; Chicago

• Dimensions (WHD)
• 21 x 7 x 7.375 inch / 533 x 178 x 187 mm

• External source of data
• Ernst Erb

• Source of data
• Radio Collector`s Guide 1921-1932

• Other Models

• Here you find 46 models, 18 with images and 1 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
  All listed radios etc. from Premier Electric Co.; Chicago (IL)
