Mira Electrónica PGV-625

Promax; Barcelona

Data
Forum
Pictures
Collections

  • Year
  • 1974
  • Category
  • Service- or Lab Equipment
  • Radiomuseum.org ID
  • 173793

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Transistors
  • Semiconductors present.
  • Semiconductors
  • Wave bands
  • VHF incl. FM and/or UHF (see notes for details)
  • Power type and voltage
  • Alternating Current supply (AC) / 125; 220 Volt
  • Loudspeaker
  • - - No sound reproduction output.
  • Material
  • Metal case
  • from Radiomuseum.org
  • Model: Mira Electrónica PGV-625 - Promax; Barcelona
  • Shape
  • Tablemodel without push buttons, Mantel/Midget/Compact up to 14
  • Notes
  • Salida TV: FI/ZF/IF; B1, B3, B4, B5. Sistemas B & G CCIR
  • Literature/Schematics (1)
  • Anuncio Revista Española De Electrónica 241 Dic 1974
  • Author
  • Model page created by Miguel Bravo-Cos. See "Data change" for further contributors.
