• Country
• Australia

• Manufacturer / Brand
• Pye Electronics Pty Ltd, Melbourne

• Year
• 1955

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 196155

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 5

• Valves / Tubes
• 6AN7 6BH5 6BD7 6M5 6V4

• Main principle
• Superheterodyne (common); ZF/IF 455 kHz; 2 AF stage(s)

• Tuned circuits
• 6 AM circuit(s)

• Wave bands
• Broadcast plus more than 2 Short Wave bands.

• Power type and voltage
• Alternating Current supply (AC) / 200-225; 225-250 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)

• Material
• Bakelite case

• from Radiomuseum.org
• Model: 7 M.S.P. - Pye Electronics Pty Ltd,

• Shape
• Tablemodel, low profile (big size).

• Dimensions (WHD)
• 432 x 253 x 217 mm / 17 x 10 x 8.5 inch

• Notes
• This model has four band spread short wave ranges covering the 31, 25, 19 and 16 metre bands.

• Circuit diagram reference
• Australian Official Radio Service Manual Vol. XIV

• Author
• Model page created by Stuart Irwin. See "Data change" for further contributors.

• Other Models

• Here you find 29 models, 22 with images and 20 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
  All listed radios etc. from Pye Electronics Pty Ltd, Melbourne
