• Country
• Australia

• Manufacturer / Brand
• Tecnico Electronics Pty Ltd Sydney

• Year
• 1958/1959

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 196794

• • Brand: Tecnico-Aristocrat, Tecnicorda, Pye-Tecnico

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 5

• Valves / Tubes
• 6BE6 6BA6 6AV6 6AQ5 6V4

• Main principle
• Superheterodyne (common); ZF/IF 455 kHz; 2 AF stage(s)

• Tuned circuits
• 6 AM circuit(s)

• Wave bands
• Broadcast only (MW).

• Power type and voltage
• Alternating Current supply (AC) / 200 - 260 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 4 inch = 10.2 cm

• Material
• Plastics (no bakelite or catalin)

• from Radiomuseum.org
• Model: Pye Ranchero MR-1 - Tecnico Electronics Pty Ltd

• Shape
• Tablemodel without push buttons, Mantel/Midget/Compact up to 14

• Dimensions (WHD)
• 13.5 x 5.75 x 6 inch / 343 x 146 x 152 mm

• Notes

• PYE MR-1 "Ranchero" Mantel

  Strikingly styled in a cabinet of very compact dimensions, the PYE "Ranchero" Mantel Model Radio provides outstanding radio reception. Great rigidity and tonal depth is derived from the solid cast-metal front frame, while the incorporation of a printed circuit assures years of reliable operation. High quality reproduction of records is possible through the use of a record player connected to the specially provided terminals. The white front grille is attractively trimmed with chromed fittings, and an all-States 'hairline' tuning dial.

  In charcoal grey, dove grey or coral red. (MINGAY'S PRICE SERVICE)

  See also Ranchero Model MR-2 & Executive TM6 Models R15-2A, R15-2B & R15-2C

• Price in first year of sale
• 26.25 AUS £

• Mentioned in
• Mingay's Price Service (Nov 1958 to Aug 1959.)

• Literature/Schematics (1)
• - - Manufacturers Literature (Pye Radio Service Data.)

• Literature/Schematics (2)
• J.R. Publications Radio Service Handbook (R.V. Series Vol. 1, 1963, Page P211.)

• Author
• Model page created by Stuart Irwin. See "Data change" for further contributors.
