Monitor Receiver PTC 145
Pye Ltd., Radio Works; Cambridge
- Country
- Great Britain (UK)
- Manufacturer / Brand
- Pye Ltd., Radio Works; Cambridge
- Year
- 1956
- Category
- Commercial Receiver (may include amateur bands)
- Radiomuseum.org ID
- 249430
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 8
- Main principle
- Superheterodyne (common); 2 AF stage(s)
- Tuned circuits
- 14 AM circuit(s)
- Wave bands
- Wave Bands given in the notes.
- Power type and voltage
- Alternating Current supply (AC) / 90-250 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 7 cm = 2.8 inch
- Power out
- 0.25 W (unknown quality)
- Material
- Metal case
- from Radiomuseum.org
- Model: Monitor Receiver PTC 145 - Pye Ltd., Radio Works;
- Shape
- Tablemodel without push buttons, Mantel/Midget/Compact up to 14
- Dimensions (WHD)
- 254 x 215 x 165 mm / 10 x 8.5 x 6.5 inch
- Notes
-
Überwachungsempfänger, 1 oder 4 Kanäle, Quarzsteuerung (Steckquarze), Amplitudenmodulation.
Verschiedene Versionen: Frequenzbereich 79 - 103 MHz (Polizei und Feuerwehr in GB), 118 - 136 MHz (ziviler Flugfunk).Similar to the Irish device PYE PTC-145
- Net weight (2.2 lb = 1 kg)
- 6.1 kg / 13 lb 7 oz (13.436 lb)
- Mentioned in
- -- Original-techn. papers.
- Author
- Model page created by Heiko zur Mühlen. See "Data change" for further contributors.
