Portable Stereo Record Player with MW/LW 1013/LW

Pye Ltd., Radio Works; Cambridge

Data
Forum
Pictures
Collections

  • Year
  • 1968 ?
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 348851

 Technical Specifications

  • Number of Transistors
  • 11
  • Main principle
  • Superheterodyne (common); ZF/IF 470 kHz; 3 AF stage(s)
  • Tuned circuits
  • 8 AM circuit(s)
  • Wave bands
  • Broadcast (MW) and Long Wave.
  • Details
  • Record Player (not changer)
  • Power type and voltage
  • Line / Batteries (any type) / D: 4 x 1.5 / 240 Volt
  • Loudspeaker
  • 2 Loudspeakers
  • Power out
  • 1.8 W (unknown quality)
  • Material
  • Leather / canvas / plastic - over other material
  • from Radiomuseum.org
  • Model: Portable Stereo Record Player with MW/LW 1013/LW - Pye Ltd., Radio Works;
  • Shape
  • Portable set > 8 inch (also usable without mains)
  • Dimensions (WHD)
  • 16 x 3.2 x 14 inch / 406 x 81 x 356 mm
  • Notes

  • Mains/battery portable stereo record player with a built-in MW/LW radio and 2 x 0.9W transistor amplifier housed in a brief-case style case.
    Two 5 x 3-inch loudspeaker units lift off the top.

    Made in Japan.

    See also MW only Model 1013.



  • Mentioned in
  • -- Collector info (Sammler)
  • Author
  • Model page created by Gary Cowans. See "Data change" for further contributors.
