- Country
- Great Britain (UK)
- Manufacturer / Brand
- Pye Ltd., Radio Works; Cambridge
- Year
- 1939
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 202030
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 4
- Valves / Tubes
- FC2A VP2B_Mullard TDD2A QP22B
- Main principle
- Superheterodyne (common); ZF/IF 467 kHz
- Wave bands
- Broadcast (MW) and Long Wave.
- Power type and voltage
- Storage and/or dry batteries / 2 & 136.5 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
- Material
- Wooden case
- from Radiomuseum.org
- Model: PP/B - Pye Ltd., Radio Works;
- Shape
- Tablemodel with Push Buttons.
- Notes
-
Transportable battery table radio with built-in frame aerial. Eleven push buttons, six for pre-set radio stations, two for manual waveband switching, two for tone control and one for switching off.
See also two mains verions, the early PP/AC and late PP/AC
- Literature/Schematics (1)
- Trader Service Sheet (suppl. of Wireless & El. Trader, etc.) (470)
- Author
- Model page created by Howard Craven. See "Data change" for further contributors.
