- Country
- Great Britain (UK)
- Manufacturer / Brand
- Pye Ltd., Radio Works; Cambridge
- Year
- 1939 ?
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 318076
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 4
- Valves / Tubes
- FC2A VP2B_Mullard TDD2A QP22B
- Main principle
- Superheterodyne (common); ZF/IF 467 kHz
- Wave bands
- Broadcast, Long Wave and Short Wave.
- Power type and voltage
- Storage and/or dry batteries / 120 + 2.5 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 8 inch = 20.3 cm
- Material
- Wooden case
- from Radiomuseum.org
- Model: PSB - Pye Ltd., Radio Works;
- Shape
- Tablemodel with Push Buttons.
- Dimensions (WHD)
- 19 x 17 x 9 inch / 483 x 432 x 229 mm
- Notes
-
This is the battery version of the Pye PB AC Mains Set.
- Net weight (2.2 lb = 1 kg)
- 18 lb 12 oz (18.75 lb) / 8.513 kg
- Mentioned in
- - - Manufacturers Literature (PYE Service Sheet model PSB)
- Author
- Model page created by Trevor Trangmar. See "Data change" for further contributors.
