Tape Recorder 9123 TR9123A/55

Pye Ltd., Radio Works; Cambridge

Data
Forum
Pictures
Collections

  • Year
  • 1969 ?
  • Category
  • Sound/Video Recorder and/or Player
  • Radiomuseum.org ID
  • 304094

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Transistors
  • 10
  • Main principle
  • Audio-Amplification
  • Wave bands
  • - without
  • Details
  • Tape Recorder
  • Power type and voltage
  • Alternating Current supply (AC) / 110; 127; 200-250 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
  • Power out
  • 4 W (unknown quality)
  • Material
  • Wooden case
  • from Radiomuseum.org
  • Model: Tape Recorder 9123 TR9123A/55 - Pye Ltd., Radio Works;
  • Shape
  • Tablemodel, low profile (big size).
  • Dimensions (WHD)
  • 16 x 6.375 x 11.5 inch / 406 x 162 x 292 mm
  • Notes

  • A four track, two speed (1⅞ and 3¾ ips), mains powered, tropicalized tape recorder. Recording facilities include signal input mixing, loudspeaker or headphones monitoring and a meter type recording level indicator. Provision is made for using the recorder as a microphone, radio or pick-up amplifier. When used in conjunction with the stereo pre-amplifier EL3787A, stereo playback/Multiplay/Duoplay is also possible. Supplied with leads and a moving coil type N8301 microphone.

    DIN sockets for loudspeaker/headphones, radio/phono input, microphone input and for connection to a EL3787A pre-amplifier.

    Built by Philips in Austria, and similar to Philips 9123 tape recorder models.

    Elliptical loudspeaker 6 x 4 inch.

  • Net weight (2.2 lb = 1 kg)
  • 17 lb 4 oz (17.25 lb) / 7.832 kg
  • Literature/Schematics (1)
  • - - Manufacturers Literature (PYE Service Data for Tape Recorder Model 9123 V331)
  • Author
  • Model page created by Howard Craven. See "Data change" for further contributors.
