CRA-2 Capacitor-Resistor Analyzer
Pyramid Electric Company; Paterson (NJ)
- Country
- United States of America (USA)
- Manufacturer / Brand
- Pyramid Electric Company; Paterson (NJ)
- Year
- 1956 ?
- Category
- Service- or Lab Equipment
- Radiomuseum.org ID
- 289299
Label at back panel.
General inside view.
From Radio Service Dealer magazine 1957
- Number of Tubes
- 3
- Wave bands
- - without
- Power type and voltage
- Alternating Current supply (AC) / 50 - 60 Hz, 117 Volt
- Loudspeaker
- - - No sound reproduction output.
- Material
- Metal case
- from Radiomuseum.org
- Model: CRA-2 Capacitor-Resistor Analyzer - Pyramid Electric Company;
- Shape
- Book-shelf unit.
- Dimensions (WHD)
- 360 x 240 x 150 mm / 14.2 x 9.4 x 5.9 inch
- Notes
-
The Pyramid CRA-2 Analyzer is for testing Capacitors /Resistors open, shorts, and intermittents. Also for Capacitors power factor, leakage current and insulation resistance. It has an special quick check circuit which speedily locates most shorted open and intermittent Capacitors of all types while they remain connected in their operational circuits.
- Net weight (2.2 lb = 1 kg)
- 3 kg / 6 lb 9.7 oz (6.608 lb)
- Author
- Model page created by Daniel Barbitta. See "Data change" for further contributors.
