12-Kanal-Mobilstation ASG-1585
QUELLE GmbH (Universum); Fürth und Nürnberg
- Country
- Germany
- Manufacturer / Brand
- QUELLE GmbH (Universum); Fürth und Nürnberg
- Year
- 1979/1980
- Category
- Commercial Transmitter & Receiver (TRX not Amateur)
- Radiomuseum.org ID
- 177034
Bild aus Quelle Service Unterlagen
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Transistors
- 17
- Semiconductors
- Main principle
- Transceiver
- Power type and voltage
- Storage and/or dry batteries / 12 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
- Material
- Metal case
- from Radiomuseum.org
- Model: 12-Kanal-Mobilstation ASG-1585 - QUELLE GmbH Universum; Fürth
- Shape
- Chassis only or for «building in»
- Notes
- 5 IC; 12 Kanal Mobilstation, Bedienung über das Mkrofon.
- Price in first year of sale
- 298.00 DM
- Literature/Schematics (1)
- Original Quelle Service Unterlagen
- Author
- Model page created by Josef Pilz. See "Data change" for further contributors.
