9 Band Analog Weltempfänger TR 1037, Best.Nr. 145.512.0

QUELLE GmbH (Universum); Fürth und Nürnberg

Data
Forum
Pictures
Collections

  • Year
  • 1994 ?
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 152920

 Technical Specifications

  • Number of Transistors
  • Semiconductors present.
  • Semiconductors
  • Main principle
  • Superheterodyne (common)
  • Wave bands
  • Broadcast, Long Wave, more than 2 x SW plus FM or UHF.
  • Power type and voltage
  • Line / Batteries (any type) / 3 / 2x1,5 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 6.35 cm = 2.5 inch
  • Power out
  • 0.14 W (unknown quality)
  • Material
  • Plastics (no bakelite or catalin)
  • from Radiomuseum.org
  • Model: 9 Band Analog Weltempfänger TR 1037, Best.Nr. 145.512.0 - QUELLE GmbH Universum; Fürth
  • Shape
  • Very small Portable or Pocket-Set (Handheld) < 8 inch.
  • Dimensions (WHD)
  • 138 x 88 x 33 mm / 5.4 x 3.5 x 1.3 inch
  • Notes

  • Betrieb mit 3V Netzteil oder 2x 1,5V Mignon möglich.

    9Band Transistor Weltempfänger mit folgenden Bereichen:

    FM: 87,5 - 108MHz
    KW1:  5,80 -  6,20MHz (49m Band)
    KW2:  7,05 -  7,50MHz (41m Band)
    KW3:  9,50 -  9,90MHz (31m Band)
    KW4: 11,40 - 12,00MHz (25m Band)
    KW5: 15,10 - 15,65MHz (19m Band)
    KW6: 17,45 - 18,10MHz ( 16m Band)
    MW: 520 - 1650kHz
    LW: 150 - 280kHz



  • Net weight (2.2 lb = 1 kg)
  • 0.3 kg / 0 lb 10.6 oz (0.661 lb)
  • Price in first year of sale
  • 29.00 DM
  • Source of data
  • - - Data from my own collection
  • Author
  • Model page created by Guido Höh. See "Data change" for further contributors.
