• Country
• Germany

• Manufacturer / Brand
• QUELLE GmbH (Universum); Fürth und Nürnberg

• Year
• 1990 ??

• Category
• Car Radio, perhaps also + sound player/recorder

• Radiomuseum.org ID
• 159326

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• Semiconductors present.

• Semiconductors

• Main principle
• Superheterodyne (common)

• Wave bands
• Broadcast (BC) and FM or UHF.

• Details
• Cassette-Recorder or -Player

• Power type and voltage
• Storage Battery for all (e.g. for car radios and amateur radios) / 12 Volt

• Loudspeaker
• - This model requires external speaker(s).

• Power out
• 50 W (unknown quality)

• Material
• Metal case

• from Radiomuseum.org
• Model: Autoradio mit Cassettenspieler ACR 4301 - QUELLE GmbH Universum; Fürth

• Shape
• Chassis only or for «building in»

• Dimensions (WHD)
• 180 x 50 x 180 mm / 7.1 x 2 x 7.1 inch

• Notes
• Universum Autoradio mit Cassettenspieler ACR 4301, zwei oder vier Lautsprecherausgänge, LCD-Display, sechs Speichertasten, Fader-Balance-Bass-Treble, Seek, AS/PS, SDK, Auto Reverse.

• Net weight (2.2 lb = 1 kg)
• 1.2 kg / 2 lb 10.3 oz (2.643 lb)

• Author
• Model page created by Karlheinz Fischer. See "Data change" for further contributors.
