• Country
• Germany

• Manufacturer / Brand
• QUELLE GmbH (Universum); Fürth und Nürnberg

• Year
• 1971

• Category
• Television Receiver (TV) or Monitor

• Radiomuseum.org ID
• 185033

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 7

• Valves / Tubes
• PCL86 PCF802 PCL805 PL504 PY88 DY802 A61-120W

• Number of Transistors
• Semiconductors present.

• Semiconductors

• Main principle
• Superheterodyne (common)

• Wave bands
• VHF incl. FM and/or UHF (see notes for details)

• Power type and voltage
• Alternating Current supply (AC) / 220 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical

• Material
• Wooden case

• from Radiomuseum.org
• Model: Senator Electronic ST 311 Bestell Nr. 05954 - QUELLE GmbH Universum; Fürth

• Shape
• Tablemodel, low profile (big size).

• Dimensions (WHD)
• 700 x 470 x 390 mm / 27.6 x 18.5 x 15.4 inch

• Notes

• Quelle Senator 61 cm s/w mit CCIR/VHF und UHF Allbandtuner.

  Hybridgerät mit Röhren, Transistoren und integrierten Schaltkreisen.

  Volltransistorisierter VHF/UHF Tuner.

• Literature/Schematics (1)
• Original Quelle Service Unterlagen

• Author
• Model page created by Josef Pilz. See "Data change" for further contributors.
