Simonetta TG22
QUELLE GmbH (Universum); Fürth und Nürnberg
- Country
- Germany
- Manufacturer / Brand
- QUELLE GmbH (Universum); Fürth und Nürnberg
- Year
- 1967/1968
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 197911
- Number of Tubes
- 4
- Main principle
- Superheterodyne (common)
- Wave bands
- Broadcast (BC) and FM or UHF.
- Power type and voltage
- Alternating Current supply (AC) / 220 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 10 cm = 3.9 inch
- Material
- Plastics (no bakelite or catalin)
- from Radiomuseum.org
- Model: Simonetta TG22 - QUELLE GmbH Universum; Fürth
- Shape
- Tablemodel with Push Buttons.
- Dimensions (WHD)
- 325 x 150 x 110 mm / 12.8 x 5.9 x 4.3 inch
- Notes
-
Ahnlich zu Exportgerät Mivar Europa 3010 und zum italienischen Inlandsmodell Mivar Ralex, das zusätzlich über eine Möglichkeit zum Empfang von TV-Audio verfügt.
- Net weight (2.2 lb = 1 kg)
- 2 kg / 4 lb 6.5 oz (4.405 lb)
- Literature/Schematics (1)
- - - Manufacturers Literature
- Author
- Model page created by Leo Brtna. See "Data change" for further contributors.
