• Country
• Germany

• Manufacturer / Brand
• QUELLE GmbH (Universum); Fürth und Nürnberg

• Year
• 1959

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 117758

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 6

• Semiconductors
• OC613 OC612 OC612 OC604 OC604spez OC604spez OA174 OA174

• Main principle
• Superheterodyne (common); ZF/IF 452 kHz

• Tuned circuits
• 5 AM circuit(s)

• Wave bands
• Broadcast (MW) and Long Wave.

• Power type and voltage
• Dry Batteries / 9 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)

• Power out
• 0.25 W (unknown quality)

• Material
• Leather / canvas / plastic - over other material

• from Radiomuseum.org
• Model: Simonetta Zwerg Art.-Nr. 05212 - QUELLE GmbH Universum; Fürth

• Shape
• Very small Portable or Pocket-Set (Handheld) < 8 inch.

• Dimensions (WHD)
• 140 x 95 x 55 mm / 5.5 x 3.7 x 2.2 inch

• Notes

• Quelle Simonetta-Zwerg-Transistoren-Taschengerät ist ein Transistor-Portable für Batteriebetrieb.
  Quelle Bestellnummer: 05212
  Quelle Simonetta Zwerg ist offensichtlich technisch identisch
  mit Noris/Amor TK102.

  Hersteller Sommerhäuser & Friedrich.

• Net weight (2.2 lb = 1 kg)
• 0.6 kg / 1 lb 5.1 oz (1.322 lb)

• Price in first year of sale
• 99.00 DM

• Mentioned in
• -- Original prospect or advert (Quelle Werbeblatt Aug. 1959)

• Author
• Model page created by Herbert Wieler. See "Data change" for further contributors.
