• Country
• Germany

• Manufacturer / Brand
• QUELLE GmbH (Universum); Fürth und Nürnberg

• Year
• 1972–1975

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 162719

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 15

• Semiconductors
• BF314 BF353 BF195 BF194 BF194 BF194 BF194 BF194 BF194 BF194 BF194 BF194 BC173 BC108 BC309

• Main principle
• Superheterodyne (common); ZF/IF 470/10700 kHz

• Tuned circuits
• 7 AM circuit(s)     18 FM circuit(s)

• Wave bands
• Broadcast, (BC) Long Wave (LW), 2 x SW and FM or UHF.

• Power type and voltage
• Alternating Current supply (AC) / 125; 220 Volt

• Loudspeaker
• - For headphones or amp.

• Material
• Wooden case

• from Radiomuseum.org
• Model: Universum-HiFi-Stereo-5-Bereich-Tuner T715 Bestell Nr. 02011 - QUELLE GmbH Universum; Fürth

• Shape
• Book-shelf unit.

• Dimensions (WHD)
• 380 x 110 x 230 mm / 15 x 4.3 x 9.1 inch

• Notes

• Universum High Fidelity T715; 5 UKW Festsendertasten, 5 W Leistungsaufnahme, made in Germany.

  Siehe auch Südfunk Tuner T715.

• Net weight (2.2 lb = 1 kg)
• 3.3 kg / 7 lb 4.3 oz (7.269 lb)

• Literature/Schematics (1)
• -- Original-techn. papers.

• Author
• Model page created by Eberhard Franzke. See "Data change" for further contributors.
