UKW/MW Duschradio W-828
QUELLE GmbH (Universum); Fürth und Nürnberg
- Country
- Germany
- Manufacturer / Brand
- QUELLE GmbH (Universum); Fürth und Nürnberg
- Year
- 1993 ??
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 239283
- Number of Transistors
- Semiconductors present.
- Semiconductors
- Main principle
- Superheterodyne (common)
- Wave bands
- Broadcast (BC) and FM or UHF.
- Power type and voltage
- Storage and/or dry batteries / R6: 2 x 1,5 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
- Material
- Plastics (no bakelite or catalin)
- from Radiomuseum.org
- Model: UKW/MW Duschradio W-828 - QUELLE GmbH Universum; Fürth
- Shape
- Very small Portable or Pocket-Set (Handheld) < 8 inch.
- Dimensions (WHD)
- 120 x 145 x 50 mm / 4.7 x 5.7 x 2 inch
- Notes
-
Wasserdichtes Gehäuse für Bertrieb unter der Dusche; Drehknöpfe mit integrierter Gummidichtung; Aufstellbügel und Anhängekordel vorhanden; Wurfantenne für UKW; eingebaute Ferritantenne für MW
- Net weight (2.2 lb = 1 kg)
- 0.2 kg / 0 lb 7 oz (0.441 lb)
- Author
- Model page created by Michael Mischke. See "Data change" for further contributors.
